ProFX12v3 is a compact analog mixer and USB-C audio interface with features from a studio recording console. Equipped with essentials including one-knob compression, EQ, Hi-Z switches, 100 Hz low-cut filters and FX and subgroup busses, it's the perfect centerpiece for your studio.
Stream. Record. Create.
Mackie ProFX12v3 is a 12-channel professional analog mixer and USB-C audio interface with powerful enhancements for studio-quality recordings and live streams. Capture your performance with award-winning Onyx preamps, channel EQ and analog compression. Upgraded GigFX effects enhance your sound, plus you can edit and save your presets on the fly via the full-color display.
Switch between recording modes to track dry or include the FX, or use loopback mode to stream video games or perform over backing tracks without feedback. You can even bring in podcast guests over the phone via Bluetooth® on a dedicated channel. With easy connectivity, the warmth of analog and an upgraded FX engine, Mackie ProFX12v3 is the perfect centerpiece for your studio.
Standard
Capture a complete recording of your main mix to your computer, including GigFX effects and tone-shaping EQ.
Loopback
Include computer audio in your recording, great for video game streams or playing music over backing tracks.
Interface
Send untouched audio from channels 1 and 2 directly to your computer, without effects, for the cleanest recording possible.
• High-resolution GigFX ™ effects engine
• Full-color LCD display for editing and saving effects presets
• 24-Bit / 192 kHz 2x4 USB-C audio interface
• Three recording modes: Standard, Loopback and Interface
• Bi-directional Bluetooth® for music playback and caller integration
• 3-band EQ on all channels
• One-knob compression on channels 14
• Hi-Z switches allow direct connection of instruments
• 100 Hz low-cut filter and 48V phantom power on all mic channels
• Stereo 1/8" input on channel 11/12
• Separate FX, monitor and subgroup busses
• Headphone output with separate level and blend control
• Easily blend between monitoring your computer output and a latency-free feed from the mixer
• Waveform OEM™ recording software Included
• Legendary Built-Like-A-Tank design
• Solid steel chassis
• Tough ABS side protection
Mono Mic/Line: 4
Mic/Stereo Line: 3
Stereo Line: 1 or 4
Mic Preamp: 7
Global Phantom Power ( 48V): Yes
100 Hz Low Cut Filter: Yes
Channel EQ: 3-Band fixed
Channel Inserts: 4
Aux Sends: 2
Subgroups: 1
Main Outputs: XLR & 1/4"
Main Meters: 2 x 12
Level Controls: 60 mm faders
Internal FX: Stereo with 12 customizable FX processors
Compressors: 4 (knob)
Digital Recording: 2 x 4 192 kHz 24-bit
Power Supply: Internal universal 100-240 VAC
Rackmount: Optional
Weight: 7.9 lbs (3.6 kg)
Dimensions: 14.8 x 13 x 4" (376 x 330 x 101 mm)
Stream. Record. Create.
Mackie ProFX12v3 is a 12-channel professional analog mixer and USB-C audio interface with powerful enhancements for studio-quality recordings and live streams. Capture your performance with award-winning Onyx preamps, channel EQ and analog compression. Upgraded GigFX effects enhance your sound, plus you can edit and save your presets on the fly via the full-color display.
Switch between recording modes to track dry or include the FX, or use loopback mode to stream video games or perform over backing tracks without feedback. You can even bring in podcast guests over the phone via Bluetooth® on a dedicated channel. With easy connectivity, the warmth of analog and an upgraded FX engine, Mackie ProFX12v3 is the perfect centerpiece for your studio.
Standard
Capture a complete recording of your main mix to your computer, including GigFX effects and tone-shaping EQ.
Loopback
Include computer audio in your recording, great for video game streams or playing music over backing tracks.
Interface
Send untouched audio from channels 1 and 2 directly to your computer, without effects, for the cleanest recording possible.
Features
• 7 Onyx mic pres with up to 60 dB of gain and ultra-low noise performance• High-resolution GigFX ™ effects engine
• Full-color LCD display for editing and saving effects presets
• 24-Bit / 192 kHz 2x4 USB-C audio interface
• Three recording modes: Standard, Loopback and Interface
• Bi-directional Bluetooth® for music playback and caller integration
• 3-band EQ on all channels
• One-knob compression on channels 14
• Hi-Z switches allow direct connection of instruments
• 100 Hz low-cut filter and 48V phantom power on all mic channels
• Stereo 1/8" input on channel 11/12
• Separate FX, monitor and subgroup busses
• Headphone output with separate level and blend control
• Easily blend between monitoring your computer output and a latency-free feed from the mixer
• Waveform OEM™ recording software Included
• Legendary Built-Like-A-Tank design
• Solid steel chassis
• Tough ABS side protection
Specifications
Input Channels: 12Mono Mic/Line: 4
Mic/Stereo Line: 3
Stereo Line: 1 or 4
Mic Preamp: 7
Global Phantom Power ( 48V): Yes
100 Hz Low Cut Filter: Yes
Channel EQ: 3-Band fixed
Channel Inserts: 4
Aux Sends: 2
Subgroups: 1
Main Outputs: XLR & 1/4"
Main Meters: 2 x 12
Level Controls: 60 mm faders
Internal FX: Stereo with 12 customizable FX processors
Compressors: 4 (knob)
Digital Recording: 2 x 4 192 kHz 24-bit
Power Supply: Internal universal 100-240 VAC
Rackmount: Optional
Weight: 7.9 lbs (3.6 kg)
Dimensions: 14.8 x 13 x 4" (376 x 330 x 101 mm)
